ORAGUARD 290 Premium Cast 2 Mil PVC Overlaminate – Gloss & Matte

ORAGUARD 290 is ORAFOL's premium 2 mil cast PVC cold overlaminate for long-term indoor and outdoor digital graphics. Its cast construction provides high dimensional stability and the conformability needed for more demanding professional graphics, while a clear permanent solvent-based adhesive protects the printed image beneath.

Key Features & Benefits

• Premium 2 mil cast PVC construction
• Gloss and matte finish options
• Clear solvent-based permanent adhesive
• Up to 8 years durability
• UV protection extension factor of +4 years
• High dimensional stability for demanding long-term graphics
• Suitable within ORAFOL systems for vehicle, marine, transit and general signage applications

Verified Technical Specifications

Common Applications

• Long-term indoor and outdoor digital graphics
• Vehicle and fleet graphics when paired with qualified print media
• Marine graphics above the water line when used within an appropriate ORAFOL system
• Transit graphics
• Long-term general signage
• Backlit and specialty graphics when paired with compatible ORAJET media

Choosing & Using ORAGUARD Overlaminate

Choose ORAGUARD 290 when the printed graphic needs premium cast performance and long service life. It is a better match than economy or intermediate calendered laminates for demanding long-term applications. ORAFOL recommends specific media-and-laminate combinations, so match 290 to the print film and installation requirements rather than choosing by thickness alone. For solvent or eco-solvent prints, adequate outgassing before lamination is important.

Frequently Asked Questions

What is the difference between ORAGUARD 210 and 290?

210 is a 2.5 mil intermediate calendered laminate for flat short- to medium-term graphics. 290 is a thinner 2 mil premium cast laminate designed for long-term graphics and more demanding applications.

Can ORAGUARD 290 be used for vehicle graphics?

Yes, when paired with qualified ORAFOL print media and used according to ORAFOL application guidance.

How much UV protection does ORAGUARD 290 add?

ORAFOL lists a +4-year UV protection extension factor. Finished graphic life still depends on the complete print system, inks, exposure and installation.

Is ORAGUARD 290 available in matte?

Yes. ORAFOL offers standard 290 in gloss and matte finishes.
